Name: A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System
Brand: Tianjin Wavecreating Micro Intelligent Technology Co., Ltd.
Availability: InStock

Home Products Omni-directional Scanner

A WCMI SD5637 Gold Supplier China 1d 2d Code Barcode Scanner Platform Scanners Qr Barcode Reader Desktop for Pos System

Product Details:

Place of Origin:	Tianjin, China
Brand Name:	WCMI

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb
Max Paper Size:	A4 Size	Warranty(year):	15 Months
After-sales Service:	Return And Replacement, Others, Repair, Free Spare Parts, Onsite Training And Inspection, Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Gray, Black, White	Sensor:	CMOS 640*480
Light Source:	Red LED	View Angle:	Horizontal 44°, Vertical 34°
Scan Angle:	Rotation: 360°, Pitch: 60°, Deflection: 60°	Scan Mode:	Induction Mode
Precisions:	1d ≥4mil / 2d ≥10mil	Symbol Contrast:	≥15%
Weight:	<350g	Dimension:	150.32mm X 95.6mm X 88.88mm

Product Description

SD5637 omnidirectional barcode scanner is the perfect blend of affordability, performance and style. SD5637 adopts the 4th Generation I-SUBPIXEL Algorithm, which can easily read paper barcodes and screen barcodes at high speed. It adopts a new generation of lighting design with cool lighting prompt function. The SD5637 is a plug-and-play scanner, and installing it into existing checkout systems is easy. It can be widely used in supermarkets, restaurants, cinemas, pharmacies and other industries.

Product Parameters
General	Type	Wire Desktop Barcode Scanner Platform
		Product Model	SD5637
		Brand Name	WCMI
		Products Status	Stock
		Place of Origin	Tianjin,China
		Private Model	Yes
		Warranty	15 months
		After-sales Service	Return and Replacement; Free spare parts
		Certification	RoHS、FCC、CE
		Color	Black
		Language Supported	English/Customized
		Scan Element Type	CMOS
Scan Code Performance	Image (Pixels) Sensor	640 X 480 CMOS @ 100fps
		Light Source	Red LED
		View Angle	Horizontal 44°, Vertical 34°
		Decoding Capability	2d: QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417 1d: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar 、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、MSI Plessey 、RSS-14、RSS-Expand、RSS-Limited、Standard 2 of 5、Code 16K、Plessey、ChinaPost、Code49
		Depth of Field	Code39: 0~50mm （5mil） EAN13: 0~130 mm （13mil） CODE128: 0~180 mm （15mil） Wechat Payment(6 inch):0-230mm(TBD)
		Scan Angle	Rotation: 360°, Pitch: 60°, Deflection: 60°
		Scan Mode	Induction mode
		Precisions	1d ≥4mil / 2d ≥10mil
		Symbol Contrast	≥15%
Physical Parameters	Weight	<350g
		Dimensions	150.32mm x 95.6mm x 88.88mm
		Interface	USB
		Prompt Mode	LED prompt and buzzer
		Voltage	DC+5V ±5%
		Line Length	1.5m
		Current	400mA
Environmental Parameter	Operating Temperature	-20℃ ~ 60℃
		Storage Temperature	-40℃ ~ 70℃
		Operating Humidity	5%RH~95%RH (Non-condensing)

Company Information

Tianjin wavecreating Micro Intelligennt Technology CO., Ltd. is one of the leading professional R&D manufacturers for barcode scanning products in China. Our company is located in Tianjin Economic and Technological Development Area and has a registered capital of 10 million yuan. The company continuously insist on defining products from the chip, taking customized chips, image recognition algorithms and customized services as our core competency and consistently strive to improve it. The company has more than 50 employees, including 36 R&D staff, 97% of whom have a bachelor’s degree or above, 9 masters, and 2 doctors.

Packing & Delivery

Certification

FAQ

1. Is OEM or ODM available?

Yes. We are the factory directly. We can make it as your requirement.
2. What’s the warranty policy for the barcode scanners?
We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is
necessary for replacement or new barcode scanners replacement in the next order.
3. Why so competitive?
We have a professional R & D team and technical team and have a large domestic market. So large quantity will reduce our raw material cost directly. What's more, we have mature technology to save costs.
4. How to control the performance stability?
We take the flow line production in the whole processing. Every product will test 4 times at least before it is delivered.
5. How about the factory?
We have more than 200 workers with an advanced dust-free plant. We are approved the new high-tech enterprise by the government. Owned many technical and design patents in different professional fields.
