Name: A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
Brand: Tianjin Wavecreating Micro Intelligent Technology Co., Ltd.
Availability: InStock

Home Products Barcode Scanner Module

A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module

Product Details:

Place of Origin:	Tianjin, China
Brand Name:	WCMI

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	CMOS
Colour Depth:	32 Bit	Interface Type:	Usb
Max Paper Size:	A4 Size	Warranty(year):	15 Months
After-sales Service:	Return And Replacement, Others, Repair, Free Spare Parts, Onsite Training And Inspection, Call Center And On-line Technical Support	Software Development Kit (sdk):	NO
Color:	Black	Sensor:	CMOS 640*480
Light Source:	White LED	View Angle:	Horizontal 37°, Vertical 28°
Scan Angle:	Rotation: 360°, Pitch: 60°, Deflection: 60°	Scan Mode:	Induction Mode,continous Mode,manual Mode,command-triggered Mode
Precisions:	1d ≥5mil / 2d ≥10mil	Symbol Contrast:	≥20%
Weight:	<7g	Dimension:	26mm X 22mm X 12mm

Product Description

Specification

Product Parameters
General	Type	Barcode Scanner Module
		Product model	SE4330
		Brand Name	WCMI
		Product Specification	Barcode Scanner Module
		Products Status	Stock
		Place of Origin	Tianjin,China
		Private Model	Yes
		Warranty(Year)	2yeras
		After-sales Service	Return and Replacement; Free spare parts
		Certification	RoHS FCC CE
		Color	white
		Language Supported	English/Customized
		Scan Element Type	CMOS
Scan Code Performance	Image (Pixels) Sensor	640x480 CMOS
		Light Source	White LED
		View Angle	Horizontal37°,Vertical28°
		Decoding capability	2D:QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417 1D:EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、 Code93、CodaBar、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、 MSI-Plessey、Standard 2 of 5、Plessey、China Post、 Code16K、Code 49、GS1 Databar(RSS-Expand, RSS-Limited, RSS-14)
		Depth of Field	EAN-13 40~285mm （13mil） Code39 35~140mm （5mil ） QR Code 25~185mm (15mil)
		Scan Angle	Rotation: 360°, Pitch± 45°, Deflection±45°
		Scan Speed	More than 48 times/sec
		Precisions	1d ≥4mil / 2d ≥10mil
		Motion Tolerance	More than 48 times/sec
		Symbol Contrast	≥20%
Physical Parameters	Weight	<7g
		Dimensions	26mm x 22mm x12mm
		Interface	TTL-232 /VCP /USB-HID_keyboard / USB-HID_POS
		Sleep Current	< 130 mA
		Work Current	< 230 mA
		Voltage	DC +3.3V ~ +5V (±5%)
Environmental Parameter	Operating temperature	-20℃ ~ 60℃
		Storage temperature	-40℃ ~ 70℃
		ESD Protection	Contact Discharge ±6KV, Air Discharge ±10KV
		Shock	5~200Hz，10Grms，3axes，1.5Hr
		Operating Humidity	5%RH~95%RH (Non-condensing)

Company Information

Tianjin wavecreating Micro Intelligennt Technology CO., Ltd. is one of the leading professional R&D manufacturers for barcode scanning products in China. Our company is located in Tianjin Economic and Technological Development Area and has a registered capital of 10 million yuan. The company continuously insist on defining products from the chip, taking customized chips, image recognition algorithms and customized services as our core competency and consistently strive to improve it. The company has more than 50 employees, including 36 R&D staff, 97% of whom have a bachelor’s degree or above, 9 masters, and 2 doctors.

Packing & Delivery

Certification

FAQ

1. Is OEM or ODM available?

Yes. We are the factory directly. We can make it as your requirement.
2. What’s the warranty policy for the barcode scanners?
We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is
necessary for replacement or new barcode scanners replacement in the next order.
3. Why so competitive?
We have a professional R & D team and technical team and have a large domestic market. So large quantity will reduce our raw material cost directly. What's more, we have mature technology to save costs.
4. How to control the performance stability?
We take the flow line production in the whole processing. Every product will test 4 times at least before it is delivered.
5. How about the factory?
We have more than 200 workers with an advanced dust-free plant. We are approved the new high-tech enterprise by the government. Owned many technical and design patents in different professional fields.
